Successful milling depends on a large number of factors. However, if you pay attention to a few things and operate a suitable milling cutter with the correct feed rate and spindle speed, then you are already doing a lot of things right. This way you will get good results quickly and avoid frustration and local fires.

When I built my first CNC machine, I had no idea which milling cutter to use and at what speeds, depths of cut, etc. So I randomly ordered a handful of cheap but shiny milling cutters from Aliexpress (some were even coated in bright colors!). Length, diameter, number of teeth? No idea! Then the first attempts to mill a pattern in a wooden panel: I used some random settings I had seen on Youtube and after five minutes the workpiece burned brightly…

This article is designed to help you prevent all of that. It is supposed to be firstly an introduction into the topic, e.g. to help you to understand what the different parameters do, and secondly, to be a source to look up and a help for calculating the parameters in everyday life.

There are various articles on the Internet that deal with this topic, but rarely do they go into the peculiarities of a milling machine like the ones we have. So this article also deals specifically with the limitations we face as hobbyists and how we can get around them.

How do we calculate feed rate and spindle speed?

Spindle Speed

We start with calculating the spindle speed \(n\), which is the rotational frequency of the spindle in revolutions per minute [rev/min]. Let’s take a look at the corresponding formula:

\[n = \frac{v_c \times 1000}{d \times 3.14}\]

For the calculation we only need two other values:

Cutting Speed

\(v_c\) is the so-called cutting speed [m/min], which is the velocity difference between the tool and the surface of your workpiece. This value mainly depends on the workpiece material, but also on the cutter and the rigidity of your machine.

If you buy high quality milling cutters, the manufacturer usually provides tables with \(v_c\) values dependent on the tool and material you want to use. For cheap cutters from China we unfortunately don’t have those values. The table below shows parameters as provided by the company Sorotec. These values ​​are given for their own cutters in combination with a very stiff machine. However, they give us good guide values and can later be fine-tuned for our machine:

Material \(v_c\)
Aluminum (wrought alloy) 500
Soft Plastic 600
Hard Plastic 550
Hard Wood 450
Soft Wood 500
MDF 450
Brass, Copper, Bronze 365

Some short notes about \(v_c\):

  • The stiffer the machine, the higher the cutting speeds that can be achieved. For our hobby machines, published values ​​are often very ambitious and can be reduced if needed (at the expense of production time).
  • The specified cutting speeds are mostly given for professional production, where a short tool life is often accepted for faster production times. For me it’s the other way around: I prefer to wait a little longer for a better tool life. So, another argument to lower \(v_c\) if needed.

Tool Diameter

\(d\) is the tool diameter in [mm].

  • In general: your milling cutter should be as short and thick as possible. The thickness is limited by the collet of your spindle, ER11 allows \(d\) = 7 mm max.
  • Side note: The \(\times 1000\) in the formula for \(v_c\) is only there, so that you can use mm for the tool diameter instead of meters.


Let’s assume we want to mill with a 4 mm cutter in aluminum.

We are looking for the \(v_c\) entry for aluminum in the table (500) and use \(d\) = 4:

\[n = \frac{500 \times 1000}{4 \times 3.14} = 39808\]

If the calculated value is higher than our maximum spindle speed, we have to reduce \(n\) to the highest possible value. If we take a look again at the formula, by lowering \(n\), we in fact lower \(v_c\) (if \(d\) stays constant) which should be ok, as we have seen above.

Another possibility to achieve a realistic \(n\) would be to change the tool diameter \(d\): Doubling the diameter halves the resulting spindle speed. However, since we usually start with a very limited selection of cutters, this should rarely be a real option.

My spindle can do \(n\) = 24000 max, so that’s the value I’ll take.

Feed Rate

Now that we know our spindle speed, we can calculate the corresponding feed rate \(v_f\), which is basically, how far the center line of our tool will move in one minute [mm/min]. Let’s take a look at the corresponding formula:

\[v_f = n \times z \times f_z\]

We already know \(n\), two more values are needed:

Number of Teeth

\(z\) is the number of teeth of your milling cutter. A “tooth” is a cutting edge alongside your tool.

If you buy milling cutters, they are mostly named as “1-Flute”, “2-Flute”, etc. “Flutes” are the deep helical grooves running up the cutter. There is almost always one flute per tooth, so you can use the number of flutes for \(z\).

Feed per Tooth

\(f_z\) is the feed per tooth, which is the size of the bite the tool takes per tooth and rotation [mm]. It determines the actual thickness of each chip removed by each tooth. Again, these values are usually given by the cutter manufacturer and depend on factors like the workpiece material, the tool diameter \(d\), and others. We take the table provided by Sorotec as guide values:

Material \(f_z\)
  \(d\) = 1 \(d\) = 2 \(d\) = 3 \(d\) = 4 \(d\) = 5 \(d\) = 6
Aluminum (wrought alloy) 0.010 0.020 0.025 0.050 0.050 0.050
Soft Plastic 0.025 0.030 0.035 0.045 0.065 0.090
Hard Plastic 0.015 0.020 0.025 0.050 0.060 0.080
Hard Wood 0.020 0.025 0.030 0.035 0.045 0.055
Soft Wood 0.025 0.030 0.035 0.040 0.050 0.060
MDF 0.030 0.040 0.045 0.050 0.060 0.070
Brass, Copper, Bronze 0.015 0.020 0.025 0.025 0.030 0.050


We continue our example from above, assuming that our 4 mm cutter has 4 teeth.

We use \(n\) = 24000 and \(z\) = 4, then we are looking for the \(f_z\) entry for aluminum and \(d\) = 4 in the table (0.050):

\[v_f = 24000 \times 4 \times 0.05 = 4800\]

For professional machines it might not be any problem to go that fast, but for a hobby machine 4800 mm/min can be completely out of reach.

So, what could we change? Let’s take a look at the formula:

  • We could further lower \(n\) (and, thereby, \(v_c\)) but we already did, so maybe there are better ways.

  • A simple way to achieve feasible values ​​is to change the number of teeth. Since \(z\) is a simple factor, halving \(z\) also means halving the feed rate.

In our example, \(z\) = 2 would lead to \(v_f\) = 2400, or \(z\) = 1 would lead to \(v_f\) = 1200.

The 4-flute cutter from the example was chosen to illustrate one of the problems, we might have with those cutters. They should theoretically produce better surfaces but they need feed rates we might not be able to achieve with our machines (There is more about pros and cons for different cutters but maybe that’s a topic for another article).

My shiny 4-flute cutters that I originally bought are all on the shelf and I almost only mill with 1- and 2-flute cutters, partly because they give me feed rates that I can realize. Here is a list of cutters I use.

That’s it for now, I hope it wasn’t too long! If you have questions or comments feel free to join our facebook group!

Happy milling!
